Product information "Adafruit RFM69HCW, radio module, 433MHz, SPI interface, IoT home automation, 1.8 to 3.6 V"

RFM69HCW 433 MHz transceiver radio module
The RFM69HCW 433 MHz transceiver radio module is a radio module that was developed for data transmission over long distances. It operates in the licence-free 433 MHz ISM band and is suitable for applications where a long range is required but high data rates are not needed. Typical applications include sensor networks, remote control and data transmission in rural areas.

Features at a glance

Based on the SX1231 chip with SPI interface
Supported modulations: FSK, GFSK, MSK, GMSK, OOK
Integrated temperature sensor
Automatic frequency tuning (AFC)
Wake-up timer and preamble detection
Encrypted communication using AES-128
Support for multipoint networks with individual node addresses
Packet-orientated communication with error correction and automatic repetition

Compatibility with

Arduino and other microcontrollers with SPI interface
Radio modules of the type RFM69HCW 433 MHz

Technical specifications

Operating voltage: 1.8 to 3.6 V
Output power: +13 to +20 dBm (up to 100 mW), adjustable via software
Range: approx. 500 metres with line of sight, can be extended to up to 5 km with directional antennas and optimised settings
Power consumption: 50 mA (+13 dBm) to 150 mA (+20 dBm) when transmitting, approx. 30 mA in receive mode
Sensitivity: -120 dBm
Data rate: up to 300 kbps
66-byte FIFO memory for transmit and receive data
Dimensions: 16 x 16 mm

Scope of delivery

1x RFM69HCW 433 MHz transceiver radio module

Zolltarifnummer:	85177000
Brand:	Adafruit
Country of Origin:	China
Gross Weight (kg):	0.010
Manufacturer ID:	5693
Product ID:	ADA5693
