SparkFun WAV Trigger, 16 triggers, 14 tracks, 2W RMS, MIDI control, 16 bit, 44.1kHz, stereo

Product number: WIG-13660

€64.90

Prices incl. VAT plus shipping costs

Available · 1 piece · 1-3 days

€64.90*

SparkFun WAV Trigger, 16 triggers, 14 tracks, 2W RMS, MIDI control, 16 bit, 44.1kHz, stereo

Order now and secure 33 Berrys

Product information "SparkFun WAV Trigger, 16 triggers, 14 tracks, 2W RMS, MIDI control, 16 bit, 44.1kHz, stereo"

WAV Trigger - High-quality polyphonic audio player
SparkFun's WAV Trigger is a unique, high-quality polyphonic audio player with amazing capabilities. It supports up to 2048 uncompressed 16-bit, 44.1kHz WAV files - the same quality as an audio CD - and can play and mix up to 14 stereo tracks simultaneously and independently, with very low latency. Tracks can be controlled via 16 programmable trigger inputs, a native serial control protocol or even MIDI.

Features at a glance

Supports up to 2048 uncompressed 16-bit stereo WAV files at 44.1kHz - CD quality
Polyphonic! Plays and mixes up to 14 stereo tracks independently and simultaneously
Trigger-to-sound delay: Typically 8 ms, maximum 12 ms
MIDI control: Speed-sensitive triggering of up to 16 banks of 128 tracks
Real-time playback speed control and MIDI pitch bend
Pause and resume individual or groups of tracks. Multiple randomised trigger ranges

Technical specifications

True line-level stereo output: 2.1V RMS, centre grounded, 100dB SNR
On-board mono audio amplifier and speaker connection: 2W into 4 ohms, 1.25W into 8 ohms
16 trigger inputs are individually adjustable for contact closure, 3.3V or 5.0V control
Supports both SDSC (up to 2GB) and SDHC (up to 32GB) type microSD cards

Other data

MIDI channels and note numbers are mapped to track numbers
MIDI controllers adjust volume as well as attack and release times
MIDI programme change is supported to switch between up to 16 banks with 128 sounds

Scope of delivery

1x WAV Trigger Module
1x connection cable
1x documentation

Zolltarifnummer:	85340090
Brand:	SparkFun
Country of Origin:	USA
EAN:	5055421077983
Gross Weight (kg):	0.019
Manufacturer ID:	WIG-13660
Product ID:	WIG-13660

Manufacturer information
SparkFun Electronics
6333 Dry Creek Parkway
DE CO 80503 Niwot
https://www.sparkfun.com
[email protected]

WEEE number: 17968585

Responsible person for the EU
Sertronics GmbH
Am Studio 20d
DE 12489 Berlin
https://www.berrybase.de
[email protected]

Safety instructions

Avoid direct mechanical stress or damage to the product.
Only use the product in accordance with the manufacturer's instructions and specifications.
Protect the product from moisture, extreme heat or cold.
Do not operate in potentially explosive atmospheres unless expressly designed for this purpose.
Ensure correct cabling and prevent short circuits.
Only use compatible voltage sources and power supply units.
Keep the product away from strong sources of electromagnetic interference.
Avoid direct contact with water- or solvent-based substances.
Dispose of the product in accordance with the applicable environmental and electronics regulations.
Carry out recycling in accordance with the WEEE Directive or local regulations.
For products with batteries, remove them before disposal and recycle them separately.
Do not dispose of with household waste; use specialised recycling centres.
