Product information "SparkFun LED Driver Breakout - TLC5940 (16 Channel)"

The TLC5940 is a 16-channel PWM device with 12-bit duty cycle control (0-4095), 6-bit current limit control (0-63) and a serial daisy-chain capable interface. This breakout board is a great way to take full advantage of this useful IC. All 16 PWM channels are broken out on standard 0.1" leads that run alongside convenient power and ground rails. As the TLC5940 can also be connected in series, the breakout is designed to support this function. On the left side of the board, all serial inputs are broken out to 0.1" headers, as are the outputs on the right side.

Use this board to increase the number of PWM pins available to your microcontroller for applications such as monocolour, multicolour or full-colour LED displays, LED signs, display backlighting, servo control or any other project where a large number of PWM drivers are required.

**Note: **While each 3-pin PWM header is spaced 0.1" apart, the spacing between each header is slightly larger to accommodate servo connections. To make the board suitable for use with servos, 2.2k pull-up resistors are fitted to each output. The 2.2k resistor on the Iref pin sets the output current to 17.8mA, but a parallel through-connector is provided for an additional resistor to increase the current if required. To determine the required resistor value for a given output, check the equations on the circuit diagram.

Documents:

Properties

Zolltarifnummer: 85423919
Brand: SparkFun
Country of Origin: USA
EAN: 5904422370503
Gross Weight (kg): 0.005
Manufacturer ID: BOB-10616
Product ID: BOB-10616

Manufacturer

SparkFun

SparkFun – open-source electronics from Colorado

SparkFun Electronics was founded in Boulder, Colorado in 2003 and is one of the defining companies of the maker movement. The idea behind it: electronics should be accessible to everyone. That is why SparkFun publishes the schematics and layouts of its products as open-source hardware and accompanies them with detailed guides and tutorials.

Development and manufacturing take place in the USA. SparkFun is best known for the Qwiic system, which allows sensors and modules to be combined via plug connection without soldering, as well as for the Thing Plus and MicroMod platforms for IoT and embedded projects.

At BerryBase you will find a large selection of genuine SparkFun products – from breakout boards for quick prototypes to development boards for professional applications.

Manufacturer and safety information

Manufacturer information
SparkFun Electronics
6333 Dry Creek Parkway
DE CO 80503 Niwot
https://www.sparkfun.com
[email protected]

WEEE number: 17968585

Responsible person for the EU
Sertronics GmbH
Am Studio 20d
DE 12489 Berlin
https://www.berrybase.de
[email protected]

Safety instructions
  • Do not use the LED controller in damp or wet environments unless it is expressly labelled as waterproof.
  • Only operate with the specified operating voltage and current to avoid damage or short circuits.
  • Do not use damaged cables or plugs to avoid the risk of electric shock or fire.
  • Avoid direct sunlight or extreme heat to prevent the appliance from overheating.
  • Children and untrained persons may only use the appliance under supervision.
  • To prevent injury or damage, do not open or tamper with the appliance during operation.
  • In the event of a defect or malfunction, disconnect the appliance and have it checked by qualified personnel.
  • For disposal: Do not dispose of in household waste, but recycle in accordance with local regulations for electronic waste or hand in at collection points.
  • Ensure that batteries (if used) are separated and disposed of properly.
  • During intensive use, always ensure adequate ventilation to prevent heat build-up.
